G07-L1-0003
Co.Par FIX BOARD · Pilar · 400 mm · central
Steel · cathodic coating (KTL)
Centre pillar of the Fix Board fixed dropside system, height 400 mm, for dropside of 25 mm, with one interlocking pocket and dimensions A=400 · B=345 · C=55 mm. Steel body with cathodic coating treatment — a protective primer that evens out the coverage and increases corrosion resistance, but requires a finish coat of paint.
Specifications
- Dimensions
- H=400 mm · A=400 · B=345 · C=55 mm · sheet/dropside 25 mm
- Weight
- 8,70 kg
- Position
- Centre
- Vehicle area
- Pillar
- Technical data
- Steel; cathodic coating (KTL) primer + paint; accepts dropside 25 mm; pockets/galvanised end fittings · H=400 mm · A=400 · B=345 · C=55 mm · sheet/dropside 25 mm. 1 window(s) interlocking («windows»)
Identification
- Manufacturer reference
- FMAA400CENN7
- Brand
- Co.Par
- Type
- Component
CATAPHORESIS IS A PRIMER: corrosion resistance is only guaranteed with a top coat over it (declared by the manufacturer).
